300 kW prime / 330 kW standby open frame diesel generator set built for construction sites, factories and remote facilities. The engine, alternator and control system are mounted on a heavy-duty steel base frame with unrestricted access to every service point, closed water-cooling and IP23 or higher protection. Available on Cummins, Perkins, Weichai and Yuchai diesel engine platforms — every unit load-tested before shipment.
|
300 kW
Prime power
|
|
330 kW
Standby power
|
|
380/220 V
Rated voltage
|
|
2006+
Manufacturer since
|
One skid-mounted package: diesel engine, alternator and control system on a rigid steel base frame, rated 300 kW prime and 330 kW standby.
The Outevo 300 kW open frame diesel generator set is a heavy-duty industrial power unit built by Shanghai Outevo Machinery Co., Ltd. for construction sites, quarries, factories and other prime or standby power applications. With the diesel engine, alternator and control system mounted on a rigid steel base frame, the unit delivers 300 kW prime power and 330 kW standby power at 380/220 V, 50 Hz, 1500 rpm. Because the open frame layout leaves every service point fully accessible, daily inspection, fuel and filter changes, parameter adjustment and fault finding can all be carried out on site without removing panels.
Every unit is assembled and load-tested on our own production lines. Shanghai Outevo Machinery Co., Ltd. has manufactured diesel and gas generator sets since 2006 from a 20,000 m² manufacturing facility, and more than 2,000 sets have been delivered to over 100 countries for mining, data center, telecom and emergency power projects. This 300 kW set is configured on Tier-1 diesel engine platforms — Cummins, Perkins, Weichai and Yuchai — matched to the alternator for the rating and equipped with a closed intelligent water-cooling system with forced cooling fan and large-capacity water tank for precise temperature control under continuous load.
Designed for harsh and remote conditions, the unit is protected to IP23 or higher and can be upgraded for dusty, humid, rainy or high-temperature environments. It serves as prime power for construction sites, quarry and mining operations, oil and gas field works and remote facilities, and as standby power for factories, workshops, warehouses and commercial buildings. Outevo’s manufacturing range covers 10–3,750 kVA in open frame, silent, containerized and mobile configurations, so the same engineering and service standard applies across the line.
The engine, alternator and control system are mounted on a rigid fabricated steel base frame with integrated anti-vibration mounts. The open layout keeps every service point reachable, so inspection, fuel and filter changes and fault finding can be carried out on site without removing panels, reducing downtime and maintenance cost.
Rated 300 kW prime and 330 kW standby at 380/220 V, 50 Hz, 1500 rpm, the set handles continuous prime power on construction and mining sites as well as automatic standby duty for factories, workshops and commercial buildings, with capacity headroom for motor starting loads.
Diesel engines are selected from Cummins, Perkins, Weichai and Yuchai platforms and matched to the alternator for each power rating. Coupling, alignment and full-load testing are carried out in our own production facility before shipment, and the engine platform is confirmed with you at order stage.
A closed intelligent water-cooling system with forced cooling fan and large-capacity water tank maintains precise temperature control, allowing stable operation in high ambient temperatures and long continuous load cycles in dusty or high-humidity sites.
Sealed dustproof, waterproof and anti-corrosion treatment to IP23 or higher, upgradable upon customization for demanding environments. The set keeps running in dust, rain, snow and temperature extremes, extending service life in outdoor and industrial applications.
Optional automatic transfer switch (ATS), remote monitoring module, cable winch and quick connectors simplify on-site wiring and start-stop procedures. Skid or base-frame mounting, control and protection schemes, and voltage and frequency settings are configured to the project specification under OEM/ODM terms.
Standard open frame configuration at 300 kW prime / 330 kW standby. Ratings, voltage and frequency are configured to your project specification.
Engine platformCummins · Perkins · Weichai · YuchaiDiesel engines are selected from these Tier-1 platforms and matched to the alternator for each power rating. The platform for your order is confirmed at order stage. |
Control & protectionATS & remote monitoringOptional automatic transfer switch for automatic standby start, plus an optional remote monitoring module. The control and protection scheme is set to your project specification. |
Build configurationOpen frame standardThis model ships as an open frame set. Silent, containerized and mobile configurations are available across the 10–3,750 kVA range under OEM/ODM terms. |
1. Construction site operationsPrime power for tower cranes, welding sets, concrete equipment, dewatering pumps, lighting towers and temporary site offices where no fixed grid is available, with stable output for construction machinery in dust, rain and temperature extremes. |
2. Factory and commercial emergency powerStandby power for production lines, compressors, CNC equipment, central air-conditioning, elevators, emergency lighting and cash register systems in factories, workshops, warehouses and commercial buildings, started automatically through an optional ATS when the grid fails. |
3. Public emergency protectionTemporary power for command centres, community emergency service stations and grassroots hospitals after natural disasters such as earthquakes and floods, supplying medical and ambulance equipment, temporary communication equipment and domestic water purification devices. |
4. Large-scale temporary activitiesCentralized power for stage lighting, audio equipment, audience area lighting and temporary catering facilities at music festivals, sporting events and outdoor exhibitions, with additional units added to match short-term high-load demand. |
5. Industrial temporary productionUninterrupted power for key production equipment such as precision instruments and temperature control systems during factory overhaul, temporary production line expansion or the infrastructure phase of a new plant, avoiding production stagnation while the main power grid is under maintenance. |
6. Infrastructure in remote areasLong-term continuous power for communication base stations, border posts and rural water supply stations far from the urban grid, where the unit operates stably over long periods in extreme temperature differences and bad weather. |
The same engineering and testing standard applies across all three builds — the difference is enclosure, access and transport.
| This model · 300 kW open frame |
| Range · 10–3,750 kVA |
| Diesel & gas |
| Open frame · silent · containerized · mobile |
| All open frame sets |
Other ratings are built to order within the 10–3,750 kVA range. Send us your required power, voltage and frequency and we will return a configuration.
Tell us the rating, voltage and frequency you need and where the unit is going. Our engineering team returns a configuration and quotation.
